Front Right Side CV Axle Shaft fit for Chevrolet Impala L4 2.5L 2014-18 01193296

Function:

CV Axles serve as the final link between the engine and the wheels, transferring power from the vehicle's transmission and differential to the wheels to drive the vehicle forward.And ensure the stability and safety of the car when turning or driving on uneven roads.

Application

fit for Buick Allure L4 2.4L Front Left or Front Right 2010 ，
fit for Buick Allure V6 3.6L Front Left or Front Right 2010 ，
fit for Buick LaCrosse L4 2.4L Front Right 2010-2016 ，
fit for Buick LaCrosse V6 3.0L Front Left 2010 ，
fit for Buick LaCrosse V6 3.6L Front Left or Front Right 2010-2016 ，
fit for Buick Regal L4 2.0L Front Left or Front Right 2014-2016 ，
fit for Buick Regal L4 2.0L Front Left or Front Right Automatic trans 2014-2016 ，
fit for Buick Regal L4 2.0L Front Right 2017 ，
fit for Buick Regal L4 2.0L Front Right Automatic trans. 2012-2013 ，
fit for Buick Regal L4 2.4L Front Right 2011 ，
fit for Buick Regal L4 2.4L Front Right 2014-2017 ，
fit for Cadillac XTS V6 3.6L Front Left 2014-2015 ，
fit for Cadillac XTS V6 3.6L Front Left or Front Right 2016-2018 ，
fit for Cadillac XTS V6 3.6L Front Left or Front Right Trans. code 6T70 2016-2018 ，
fit for Cadillac XTS V6 3.6L Front Left Trans. code 6T70 2013 ，
fit for Cadillac XTS V6 3.6L Front Left Trans. code 6T70; Trans. code 6T80 2014 ，
fit for Cadillac XTS V6 3.6L Front Left 2019 ，
fit for Cadillac XTS V6 3.6L Front Left Trans. code 6T70 2015 ，
fit for Cadillac XTS V6 3.6L Front Left Trans. code 6T70 2019 ，
fit for Chevrolet Impala L4 2.5L Front Right 2014-2018 ，
fit for Chevrolet Impala V6 3.6L Front Left 2019-2020 ，
fit for Chevrolet Impala V6 3.6L Front Left or Front Right 2014-2018 ，
fit for Chevrolet Malibu L4 2.0L Front Left or Front Right 2013-2015 ，
fit for Chevrolet Malibu L4 2.4L Front Right 2013-2014 ，
fit for Chevrolet Malibu L4 2.5L Front Right 2013-2015 ，
fit for Chevrolet Malibu Limited L4 2.5L Front Right 2016 ，
Note-1: fit for Buick Regal L4 2.0L 2012-2016, it fits Automatic Transmission, not Manual Transmission
Note-2: fit for Cadillac XTS 2013, it fits Transmission Code 6T70, not 6T75
Note-3: fit for Cadillac XTS 2014-2019, it fits Transmission Code 6T70 or 6T80, not 6T75


OE/Part number

66-1513,60-1513,13228208,22743589,22796199,22870111,661513,601513

Specification

Condition:New
Type:CV Axle Assembly
Color：Black
Placement on Vehicle：Front Left,Right
Axle Nut Locking Type: Self-lock
Surface Finish:Black Coating
Output Shaft Connection Style:Splined
Input Shaft Connection Style: Splined
Output Shaft Spline Count:30 Teeth
Input Shaft Spline Count: 27 Teeth
Compressed Length(IN):25.413 in

Package included

       1Pcs CV Axle Assemblies (Front Left/Right)

Feature

1.Unparalleled Performance:precision Machining,professional heat-treating,high-performance Neoprene Material can resist to grease and extremes of temperature and superior flexibility minimizing wear and tear.It realizes excellent durability and longevity．

2.Durable structural design：Steel 55 Ball Cage,Constant Velocity,Smooth Transmission.

3.Safe and Pleasing Experience: CV Joint Axle improve stability and comfort fit for driving.

4.Direct Replacement:Complete set CV alxe assembly easy to install.

5.Superior Package Design：With good cushioning and isolation performance, effectively protect products from damage, environmentally friendly and recyclable.

Note

*Please confirm your vehicle condition and OE number before placing an order!
*Please note that this is an after-sales part, not an original part.
*We suggest that you seek professional installation to avoid unnecessary trouble.
*If you have any questions, please contact us.
