FIT for Air Compressor 5 HP Electric Motor 3450RPM 230V 15A 56Frame 5/8" Shaft CCW 84166521

Application:

FIT For General purpose motor is suitable for general equipment.

Specification:

Enclosure Type:ODP (Open Drip-Proof)

Model:5 HP SPL motor

Current Type: AC

AC Phase: Single Phase

AC Frequency Rating:60 Hz

Voltage: 230V

Horsepower: 5HP SPL

Rotation Speed:3450RPM

Frame Size:56

Rated Current/ Full Load amps: 15A

Shaft Length: 1.88"

Shaft Diameter:5/8" Keyed Shaft

Shaft Type: Keyed

Rotation: CCW

Mounting Type: Base-Mounted

Part Type: 5 Hp Air Compressor

Service Factor: 56

Package Include:

1 x Compressor Electric Motor

Feature:

1. Air Compressor Motor: 5 Horse Power, 56 Frame, Open Drip-Proof, Rotation - CCW, Rotation speed - 3450RPM, Shaft diameter - 5/8", Shaft length: 1.88".

2. This Air Compressor Electric Motor is designed with an open drip-proof feature that ensures the motor's longevity by preventing water and dust from entering.

3. This electric motor features a reversible function for CCW, offering versatility and convenience for various applications.

4. Constructed with high-quality materials, this durable electric motor promises long-lasting use and excellent resistance to wear and tear.

Note:

- Suggest using in clean and dry environments.

- Please purchase motor according to the specific needs of the parameters.

- If you have any questions, pls feel free to contact us!
