Cooling System Radiator fit for Cadillac CTS 3.6L 2008-2014 CU13109 Direct Fit 92358221

Application:

fit for 2008 Cadillac CTS V6 3.6L Engine VIN V

fit for 2009 Cadillac CTS V6 3.6L 24 Valve DOHC Naturally Aspirated Engine VIN V

fit for 2010-2013 Cadillac CTS V6 3.0L

fit for 2010-2013 Cadillac CTS V6 3.6L

fit for 2014 Cadillac CTS Coupe V6 3.6L

fit for 2014 Cadillac CTS Sedan V6 3.0L

fit for 2014 Cadillac CTS Wagon V6 3.0L

fit for 2014 Cadillac CTS Wagon V6 3.6L

OE/Part number:

13055,CU13055,13108,CU13108,13109,CU13109,13478,GM3010521,GM3010522,15932852,15932855,25789911,25789912,20983746,15932854,25957496

Specification:

Condition: New

Fitment Type: Direct Replacement

Placement on Vehicle: Engine Compartment

Core Material：Aluminum

Tank Material：Plastic

Core Size：23-5/8" X 20-3/8" X 5/8"

Inlet Diameter：1-5/16"

Inlet Location：Top Right

Outlet Diameter：1-5/16"

Outlet Location：Bottom Left

Core Row Quantity：1

Down Flow Or Cross Flow Type：Crossflow

Engine Oil Cooler Included：No

Transmission Oil Cooler Included：Yes

Transmission Type：AT

Package Includes: 1 x Radiator (Showing as the picture)
