GT3782VAS Turbocharger fit for Ford F-250 F-350 6.0L 2005-2007 743250-5013 67856690

Application

fit for Ford F-Series F-250, F-350 Truck Super Duty 6.0L Power stroke Engine 2005-2007

OE/Part number

743250-5013, 7432505013S, 743250-5013S,

743250-0014，743250-5014S，743250-5014,

743250-0004, 743250-5004S，7432509004, 743250-9004,

743250-0002, 743250-5002S，743250-0001，

743250-0005, 743250-5005，743250-9005,

743250-0016，743250-5016，743250-9016

743250-0021，743250-5021，743250-9021，

170025-0109,

1877831C93, 1879413C94, 1879413C92, 1879413C93, 1877832C93,

1877832C91, 1877832C92, 1832255C91, 1832255C92,

1877834C91, 1876493C91, 1877831C91, 1877834C91, 1879413C91,

1854480C91,1854480C91,1845178C98,

1845178C95,1854593C91,1854593C92,1854593C94,

1832159C91, 1843761C93, 1843761C94,

1845322C91, 1846765C91, 1846767C91, 1882379C2,

1858116C91,1882380C1,100211R,

5010147R93, 5010399R91, 5010422R91,

4C3Z6K682CB, 4C3Z6K682CBRM，4C3Z6K682CCRM,

5C3Z6K682AA, 5C3Z6K682A, 5C3Z6K682DA, 5C3Z6K682CA ,

5C3Z6K682CCRM, 5C3Z6K682CARM

Specification

Turbo Model: GT3782VAS, GT3782VA

Engine: Power stroke

Cooling Type：Oil Cooled

Bearing Type: Journal Bearing / Floating Bearing

Thrust bearings: 270 Degrees

Hosepower: 242KW/325HP

Actuator Type: Electronic Actuator

Turbo Type: Individual/VNT

Universal Fitment: No

Finish:Matte

Condition: Brand New

Package Size: 35*34*38.5 cm

Package Weight: 19900g

Accessories: You will receive the parts exactly as shown in the picture above.

Package included

1 x Turbocharger

1 x Manual

1 x Brochure

1 x Sticker

Feature

* Product Material

1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃

2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃

3. Compressor housing: ZL104 aluminum with lightweight

4. Compressor wheel: Cast aluminium blades – superior air tightness & corrosion resistance

* Product

1. OEM-quality and size with little modification

2. Rich experience in turbo production and own factory

3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:

1. 100% balancing Test by TURBOTECHNICS VSR3

2. G3-min-Flow VNT Turbo testing

3. Advanced Actuator Tester/Programmer

Note

* Please confirm your original turbo PART NUMBER before Purchasing

* Professional installation is highly recommended

* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
