K04 TurboCharger fit for Mazda CX7 CX-7 mazdaspeed 3 2.3L 06 07 08 09 10 K0422-582 35491560

Introduction：

This K0422-582 Turbocharger is a direct replacement turbo fit for Mazda CX-7 2006-2014 2.3L engines.The K04 turbocharger is designed to be used on engines displacing 1.8L-2.5L and is typically good fit for around 300HP. Recommended boost pressures are 7psi(0.5 Bar) to 21psi(1.5 Bar) and boost pressures should not exceed 30psi(2 Bar). This Turbo is Capable of boosting horse power up to 300+ BHP.

Turbo Turbocharger fit for Mazda CX-7 CX7 2.3L Turbocharged 06-14 K04

Engine fit for:

fit for Mazda CX-7 2.3L MZR DISI 2.3 Turbo L3-VDT engine 190kW 258HP 2006-2014
fit for Mazda speed 3 2.3L with MZR DISI 2.3 Turbo L3-VDT engine 190kW 258HP 2006-2014
fit for Mazda speed 6 2.3L with MZR DISI 2.3 Turbo L3-VDT engine  190kW 258HP 2006-2014

Turbo Model :   K0422-582

Part Number:

53047109904, 53047109907,
L33L13700B, L33L13700C, L33L13700E,
L3Y11370ZC, L3Y41370ZC,L3Y31370ZC,
L3YC1370Z, L3YC1370ZA,
1323649, 71785250,

Specification:

• Exhaust (Turbo Manifold) Flange: Standard K0422 Flange fit for Mazda
• Turbocharger fit for Mazda Piping Diameter: 3.00"
• Intake Inlet/Outlet: 2.25"/ 2.25"
• Turbo Model: K0422-582
• Engine code: DISI NA
• Cooling Type: Oil+Water cooled
• Capable of boosting horse power up to 300+ BHP
• Minimum etstimated power gain about 75-100 HP
• 8psi efficient torque turbocharger
• High quality material, cast housing with durable steel

Product Material:

• Turbine housing : Ductile iron QT450-10 shell with high-temperature resistance up to 700 degrees Celsius
• Steel Turbine Wheel:Made from the special K418 alloy to achieve high oxidation resistance and stability under high temperatures up to 900 degrees Celsius
• Compressor housing:ZL104 aluminum
• compressor wheel/blades: Cast aluminium with good gas tightness and corrosion resistance

Product  Features：

• Rich Experience In Turbo Production And Own Factory
• Quality Assurance
• Strict Quality Inspection
• Precision Clearance
• High-speed Accessories
• Increase Engine Power
• Improve Emissions & Save Oil

Note

* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
